500-LFC-SX-N01-XXX

Back

To interact with the image below, use your mouse to rotate, & the mouse wheel to scroll & zoom.

ITEM NO.	DESCRIPTION
1	AT or FC connector assembly
2	optical cable (single mode or multi-mode)

Fiber Optic Cable, Patch Cord, and Pigtail Assemblies

FC Armored SS Optic Cable Assembly – 4 mm OD Cable (Yellow)

Compatibility

Available with Greene Tweed FC and ST terminations
Available in single mode and multi-mode

Environmentally Sealed

No signal degradation
Effective sealing action eliminates damage from moisture or particulate

Temperature- and Humidity-Resistant

Clarity of signal
Tested from -55°C to 85°C (-67°F to 185°F) and subjected to stringent heat/humidity with 0.5 dB maximum insertion loss

Optical Cable PVC

Good mechanical and environmental characteristics
The mechanical and physical characteristics of the PVC outer jacket meet the requirement of relevant standards
Aramid yarn material ensures good tensile strength
900 µm tight buffer helps to protect the fiber

Optical Cable Armored SS

Good mechanical and environmental characteristics
The mechanical and physical characteristics of the stainless-steel jacket provides durability and strength in harsh environments
900 µm tight buffer helps to protect the fiber

Waterproof

Sealed up to 5000 psi mated with appropriate GT Adapters or PBFs

Specifications

Ferrules are precision-machined zirconia
Made from high-quality, corrosion-resistant materials
FC-DRY™ is nickel-plated brass; FC-DRY™ HP is 316 series stainless steel (ruggedized)
Typical light loss is less than 0.5 dB per connector
